RESISTANCE   TOLERANCE

±5%            ±10%

INDEPENDENT  LINEARITY

±0.5%

TERMINAL  RESISTANCE

≤0.2%  OR  5Ω

ROTALION  NOISE

≤3%R  OR  3Ω

WITHSTAND  VOLTAGE

500AC

EFFECTTVE  ELECTRICAL  TRAVEL

3600°

TEMPERATURE  RANGE

-15℃~ +55℃

TEMPERATURE  COEFFICENT

±100ppm/℃ maximum / unit

TEMPERATURE  VARIATION

ΔR≤±2%R

COLLISION

390m/S² ,  4000 cycles  ΔR≤±1%R

VIBRATION

10~500HZ,  0.75mm, 6h ΔR≤±1%R
electric interrupt ≤100us

CLIMATE CATEGORY

ΔR≤±3%R  R1≥100MΩ

70℃ ElECTRIC ENDURANCE

2W, 1000h, ΔR≤±3%R

MECHANICAL ENDURANCE

10,000  cycles  ΔR≤±3%R,

LIFE

10,000  cycles

STEADY  DAMP-HEAT

ΔR≤±3%R, R1≥100MΩ

STARTING  TORQUE

≤36mN.m

STOP  STRENGTH

≥300mN.m
